Redundancy and Load Balancing:

PowerEdge XE8640 servers are designed for high availability and reliability. One key aspect of this design is the redundancy provided by the server's Power Supply Units (PSUs). By connecting each PSU to a different power source, you ensure that the server remains operational even if one power source fails.

Power Source Configuration:

In this scenario, the rack has two distinct power sources: one supplying power to the two left PDUs and the other to the two right PDUs. To maximize redundancy, each PSU should be connected to a different power source.

PSU Placement:

PSU 1 in the left PDUs: Connect PSU 1 to one of the PDUs on the left side of the rack. This ensures that PSU 1 is powered by the first power source.

PSU 2 in the right PDUs: Connect PSU 2 to one of the PDUs on the right side of the rack. This ensures that PSU 2 is powered by the second power source.

Ensuring Redundancy:

By placing PSU 1 on the left and PSU 2 on the right, you create a redundant power configuration. If either power source fails, the other PSU can continue to supply power to the server, maintaining its operation.

Steps for Connection:

Step 1: Verify that the rack's PDUs are correctly connected to their respective power sources.

Step 2: Identify the left and right PDUs based on their power source connections.

Step 3: Connect PSU 1 to a PDU on the left side of the rack.

Step 4: Connect PSU 2 to a PDU on the right side of the rack.

Step 5: Confirm that both PSUs are securely connected and receiving power from separate sources.

Safety and Verification:

Ensure that all connections are secure and that the cables are managed to prevent interference with other components or airflow within the rack. Verify that each PSU is functioning correctly by checking the server's power status indicators.

References:

Dell EMC PowerEdge XE8640 Installation and Service Manual: This manual provides detailed guidelines on PSU connections and power redundancy configurations.

Dell EMC Technical Specifications Guide: Offers comprehensive details on the power requirements and redundancy features of the PowerEdge XE8640.

Unpack the server from the shipping packaging.

Install the rail assembly.

Transport the server and align with the rack.

Slide the server into the rack.

Connect the power and network cables.

Power on the server.

Unpack the server from the shipping packaging:

Carefully remove the XE9680 server from its shipping packaging. Inspect the server for any visible damage and verify that all components are included as per the packing list.

Install the rail assembly:

Install the rail assemblies into the rack. Follow the instructions provided in the server's installation guide to ensure the rails are securely and correctly mounted in the rack.

Transport the server and align with the rack:

Use a server lift or appropriate equipment to transport the server to the installation site. Align the server's inner rails with the rail assemblies in the rack to prepare for sliding the server into place.

Slide the server into the rack:

Carefully slide the server into the rack along the installed rail assemblies. Ensure it is properly seated and locked into place as per the installation guidelines.

Connect the power and network cables:

Connect the server's power supply units (PSUs) to the appropriate power distribution units (PDUs) in the rack. Connect the necessary network cables to the server's network ports.

Power on the server:

After ensuring all connections are secure, power on the server. Monitor the server’s boot process and ensure it starts up correctly without any errors.

References:

Dell EMC PowerEdge XE9680 Installation and Service Manual: This manual provides detailed step-by-step instructions on unpacking, installing, and powering on the server.

Dell EMC Technical Specifications Guide: Offers comprehensive details on the hardware specifications and installation procedures for Dell PowerEdge servers.

The PowerEdge XE9680 server supports a high level of network throughput, which is achieved through its PCIe risers and network PCI card capacity. Here’s the detailed information:

PCIe Slots: The PowerEdge XE9680 server supports up to 10 PCIe Gen5 slots1. These slots are used to install PCIe devices, including network cards, which are essential for achieving high network throughput.

Riser Cards: Riser cards are used in servers to extend the PCIe slots and make them more accessible for installing additional cards, such as network cards.

Network Card Support: Each riser can support multiple PCIe network cards, allowing for expansion and increased network throughput.

Configuration: For the greatest amount of network throughput, the server can be configured with four risers, and each riser can accommodate two PCIe network cards1. This configuration maximizes the number of network cards and, consequently, the network throughput capability of the server.

By utilizing the full capacity of PCIe slots with the appropriate risers and network cards, the PowerEdge XE9680 can meet the customer’s requirement for the highest network throughput possible.

The PowerEdge XE9680 server is equipped with power supply units (PSUs) that are essential for its operation. Here’s the power consumption information that the deployment engineer can provide:

PSU Specifications: Each PowerEdge XE9680 server comes with four 2800-Watt, 15.6 Amp PSUs1. This specification is crucial for the data center manager to understand the power requirements for each server.

Total Power Requirement: With two servers per rack, each rack will have a total of eight 2800-Watt PSUs. This information helps in calculating the total power draw for each rack.

Power Distribution Units (PDUs): While the number of PDUs required for high availability can vary, it’s important to note that the server’s PSUs feature a C22 input socket1. The data center manager should ensure that the PDUs in the rack are compatible with this type of connection.

Power Planning: The data center manager must plan for the power needed to supply power to the four racks, considering the power draw of the servers and any additional equipment that will be installed.

By providing this detailed power consumption information, the deployment engineer assists the data center manager in planning for the appropriate power infrastructure to support the PowerEdge XE9680 servers.
