A common rationale for defining and applying a profile to a SysML model is that the profile extends the model with reusable elements, such as units, quantities, value types, etc. These elements can be defined in a model library and imported into other models by applying the profile. This way, the profile enables consistent and standardized modeling of properties and parameters of blocks and constraints. References: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://github.com/Systems-Modeling/SysML-v2-Release

The information in option E is necessary and sufficient for the engineering team to begin selecting and procuring COTS components for the embedded real-time control system. This information defines the timing and cost requirements and constraints for the system and its components, which are essential for evaluating and comparing the available COTS components. The other options are either incomplete or irrelevant for this purpose. For example, option A does not include the minimum period of time between critical inputs, the maximum number of critical inputs, or the cost information. Option B does not include the minimum period of time between critical inputs or the maximum number of critical inputs. Option C does not include the maximum number of critical inputs or the allocation of cost to system components. Option D does not include the maximum number of critical inputs.

The OMG specifications that UPDM uses at L1 are UML and SysML. L1 is the level of abstraction that defines the core concepts of UPDM without any implementation details. It is based on a Domain Metamodel that captures the common elements of DoDAF and MODAF. The Domain Metamodel is mapped to UML and SysML concepts using a Platform Independent Model (PIM). UML and SysML provide the basic metaclasses and diagrams that UPDM uses to represent architectures. References: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://www.omg.org/updm/

OCL is a formal language that can be used to specify constraints on the elements and relationships of a model. OCL can access the properties and operations of the model elements and check their values and states. OCL is not intended to be transformed into code or to express any imaginable constraint. OCL may not be easily understood by engineers who are not familiar with its syntax and semantics. References: OMG-Certified Systems Modeling Professional - Model Builder – Advanced (OCUP2-ADV) Examination Guide Version 1.0, Section 4.3.1

To get this model ready for solving according to the SysML-Modelica Transformation specification, one must provide specific values for the parameters and properties of the blocks, such as resistance, capacitance, voltage, etc. Also, one must define a parametric diagram that includes equations for Kirchhoff’s Laws consistent with the above ibd. A parametric diagram is a SysML diagram that shows constraints and parameters on blocks and their properties. Kirchhoff’s Laws are physical laws that describe how electric currents and voltages behave in a circuit. By defining a parametric diagram with these equations, one can specify how the blocks and connectors in the ibd are related mathematically. References: https://www.omg.org/ocsmp/ocsmp-adv-exam.htm https://www.omg.org/spec/SyM/1.0/About-SyM/
