Professional-Data-Engineer Questions and Answers

BigLake is a Google Cloud service that allows you to query structured data in external data stores such as Cloud Storage, Amazon S3, and Azure Blob Storage with access delegation and governance. BigLake tables extend the capabilities of BigQuery to data lakes and enable a flexible, open lakehouse architecture. By upgrading an external table to a BigLake table, you can improve the performance of your queries by leveraging the BigQuery storage API, which supports data format conversion, predicate pushdown, column projection, and metadata caching. Metadata caching reduces the number of requests to the external data store and speeds up query execution. To upgrade an external table to a BigLake table, you can use the ALTER TABLE statement with the SET OPTIONS clause and specify the enable_metadata_caching option as true. For example:

SQL

ALTER TABLE hive_partitioned_data

SET OPTIONS (

enable_metadata_caching=true

);

AI-generated code. Review and use carefully. More info on FAQ.

References:

Introduction to BigLake tables

Upgrade an external table to BigLake

BigQuery storage API

Private Google Access allows VMs without external IP addresses to communicate with Google APIs and services over internal routes. This reduces the cost and increases the security of the data pipeline. Custom container images can be stored in Container Registry, which supports Private Google Access. Dataflow supports Private Google Access for both batch and streaming jobs. References:

Private Google Access overview

Using Private Google Access and Cloud NAT

Using custom containers with Dataflow

The Basic Tier of Memorystore for Redis provides a standalone Redis instance that is not replicated and does not support read replicas. This means that it cannot scale horizontally to handle more read requests, and it does not provide high availability or automatic failover. If the number of read-only clients increases significantly, the Basic Tier instance may not be able to handle the demand and may impact the read and write access availability. Therefore, option A is not a good solution, as it would require creating multiple Basic Tier instances and modifying the Dataflow pipeline and the clients to distribute the load among them. This would increase the complexity and the management overhead of the solution.

The Standard Tier of Memorystore for Redis provides a highly available Redis instance that supports replication and read replicas. Replication ensures that the data is backed up in another zone and can fail over automatically in case of a primary node failure. Read replicas allow scaling the read throughput by adding up to five replicas to an instance and using them for read-only queries. The Standard Tier also supports in-transit encryption and maintenance windows. Therefore, option D is the best solution, as it would create a new Standard Tier instance with a higher capacity (5 GB) and multiple read replicas to handle the increased demand. The old instance can be deleted after migrating the data to the new instance.

Option B is not a good solution, as it would create a new Standard Tier instance with the same capacity (4 GB) and no read replicas. This would not improve the read throughput or the availability of the solution. Option C is not a good solution, as it would create a new Memorystore for Memcached instance, which is a different service that uses a different protocol and data model than Redis. This would require changing the code of the Dataflow pipeline and the clients to use the Memcached protocol and data structures, which would take more time and effort than migrating to a new Redis instance. References: Redis tier capabilities | Memorystore for Redis | Google Cloud, Pricing | Memorystore for Redis | Google Cloud, What is Memorystore? | Google Cloud Blog, Working with GCP Memorystore - Simple Talk - Redgate Software

Dataflow worker nodes need to communicate with each other and with the Dataflow service on TCP ports 12345 and 12346. These ports are used for data shuffling and streaming engine communication. By default, Dataflow assigns a network tag called dataflow to the worker nodes, and creates a firewall rule that allows traffic on these ports for the dataflow network tag. However, if you use a custom network tag for your Dataflow pipeline, you need to create a firewall rule that allows traffic on these ports for your custom network tag. Otherwise, the worker nodes will not be able to communicate with each other and the Dataflow service, and the pipeline will fail.

Therefore, the best way to identify the issue is to determine whether there is a firewall rule set to allow traffic on TCP ports 12345 and 12346 for the Dataflow network tag. If there is no such firewall rule, or if the firewall rule does not match the network tag used by your Dataflow pipeline, you need to create or update the firewall rule accordingly.

Option A is not a good solution, as determining whether your Dataflow pipeline has a custom network tag set does not tell you whether there is a firewall rule that allows traffic on the required ports for that network tag. You need to check the firewall rule as well.

Option C is not a good solution, as determining whether your Dataflow pipeline is deployed with the external IP address option enabled does not tell you whether there is a firewall rule that allows traffic on the required ports for the Dataflow network tag. The external IP address option determines whether the worker nodes can access resources on the public internet, but it does not affect the internal communication between the worker nodes and the Dataflow service.

Option D is not a good solution, as determining whether there is a firewall rule set to allow traffic on TCP ports 12345 and 12346 on the subnet used by Dataflow workers does not tell you whether the firewall rule applies to the Dataflow network tag. The firewall rule should be based on the network tag, not the subnet, as the network tag is more specific and secure. References: Dataflow network tags | Cloud Dataflow | Google Cloud, Dataflow firewall rules | Cloud Dataflow | Google Cloud, Dataflow network configuration | Cloud Dataflow | Google Cloud, Dataflow Streaming Engine | Cloud Dataflow | Google Cloud.

To ensure that both production jobs with strict SLAs and ad-hoc queries have appropriate compute resources available while adhering to cost efficiency, setting up separate reservations and billing models for each project is the best approach. Here’s why option B is the best choice:

Separate Reservations for SLA and Ad-hoc Projects:

Creating two separate reservations allows for dedicated resource management tailored to the needs of each project.

The production project requires guaranteed slots with the ability to scale up as needed, while the ad-hoc project benefits from on-demand billing based on data scanned.

Enterprise Edition Reservation for SLA Project:

Setting a baseline of 300 slots ensures that the SLA project has the minimum required resources.

Enabling autoscaling up to 500 additional slots allows the project to handle occasional spikes in workload without compromising on SLAs.

On-Demand Billing for Ad-hoc Project:

Using on-demand billing for the ad-hoc project ensures cost efficiency, as users are billed based on the amount of data scanned rather than reserved slot capacity.

This model suits the less predictable and often lower-utilization nature of ad-hoc queries.

Steps to Implement:

Set Up Enterprise Edition Reservation for SLA Project:

Create a reservation with a baseline of 300 slots.

Enable autoscaling to allow up to an additional 500 slots as needed.

Configure On-Demand Billing for Ad-hoc Project:

Ensure that the ad-hoc project is set up to use on-demand billing, which charges based on data scanned by the queries.

Monitor and Adjust:

Continuously monitor the usage and performance of both projects to ensure that the configurations meet the needs and make adjustments as necessary.

Reference Links:

BigQuery Slot Reservations

BigQuery On-Demand Pricing

For automating the CI/CD pipeline of DAGs running in Cloud Composer, the following approach ensures that DAGs are tested and deployed in a streamlined and efficient manner.

Use Cloud Build for Development Instance Testing:

Use Cloud Build to automate the process of copying the DAG code to the Cloud Storage bucket of the development instance.

This triggers Cloud Composer to automatically pick up and test the new DAGs in the development environment.

Testing and Validation:

Ensure that the DAGs run successfully in the development environment.

Validate the functionality and correctness of the DAGs before promoting them to production.

Deploy to Production:

If the DAGs pass all tests in the development environment, use Cloud Build to copy the tested DAG code to the Cloud Storage bucket of the production instance.

This ensures that only validated and tested DAGs are deployed to production, maintaining the stability and reliability of the production environment.

Simplicity and Reliability:

This approach leverages Cloud Build’s capabilities for automation and integrates seamlessly with Cloud Composer’s reliance on Cloud Storage for DAG storage.

By using Cloud Storage for both development and production deployments, the process remains simple and robust.

Google Data Engineer References:

Cloud Composer Documentation

Using Cloud Build

Deploying DAGs to Cloud Composer

Automating DAG Deployment with Cloud Build

By implementing this CI/CD pipeline, you ensure that DAGs are thoroughly tested in the development environment before being automatically deployed to the production environment, maintaining high quality and reliability.

Here's a detailed breakdown of why this solution is optimal and why others fall short:

Why Option C is the Best Solution:

Kafka Connect Bridge: This bridge acts as a reliable and scalable conduit between your on-premises Kafka cluster and Google Cloud's Pub/Sub messaging service. It handles the complexities of securely transferring data over the interconnect link.

Pub/Sub as a Buffer: Pub/Sub serves as a highly scalable buffer, decoupling the Kafka producer from the Dataflow consumer. This is crucial for handling fluctuations in message volume and ensuring smooth data flow even during spikes.

Custom Dataflow Pipeline: Writing a custom Dataflow pipeline gives you the flexibility to implement any necessary transformations or enrichments to the data before it's written to BigQuery. This is often required in real-world streaming scenarios.

Minimal Latency: By using Pub/Sub as a buffer and Dataflow for efficient processing, you minimize the latency between the data being produced in Kafka and being available for querying in BigQuery.

Why Other Options Are Not Ideal:

Option A: Using a proxy host introduces an additional point of failure and can create a bottleneck, especially with high-throughput streaming.

Option B: While Google-provided Dataflow templates can be helpful, they might lack the customization needed for specific transformations or handling complex data structures.

Option D: Dataflow doesn't natively connect to on-premises Kafka clusters. Directly reading from Kafka would require complex networking configurations and could lead to performance issues.

Additional Considerations:

Schema Management: Ensure that the schema of the data being produced in Kafka is compatible with the schema expected in BigQuery. Consider using tools like Schema Registry for schema evolution management.

Monitoring: Set up robust monitoring and alerting to detect any issues in the pipeline, such as message backlogs or processing errors.

By following Option C, you leverage the strengths of Kafka Connect, Pub/Sub, and Dataflow to create a high-throughput, low-latency streaming pipeline that seamlessly integrates your on-premises Kafka data with BigQuery.

To apply complex business logic on a JSON response using Python's standard library within a Workflow, invoking a Cloud Function is the most efficient and straightforward approach. Here’s why option A is the best choice:

Cloud Functions:

Cloud Functions provide a lightweight, serverless execution environment for running code in response to events. They support Python and can easily integrate with Workflows.

This approach ensures simplicity and speed of execution, as Cloud Functions can be invoked directly from a Workflow and handle the complex logic required.

Flexibility and Simplicity:

Using Cloud Functions allows you to leverage Python’s extensive standard library and ecosystem, making it easier to implement and maintain the complex business logic.

Cloud Functions abstract the underlying infrastructure, allowing you to focus on the application logic without worrying about server management.

Performance:

Cloud Functions are optimized for fast execution and can handle the processing of the JSON response efficiently.

They are designed to scale automatically based on demand, ensuring that your workflow remains performant.

Steps to Implement:

Write the Cloud Function:

Develop a Cloud Function in Python that processes the JSON response and applies the necessary business logic.

Deploy the function to Google Cloud.

Invoke Cloud Function from Workflow:

Modify your Workflow to call the Cloud Function using an HTTP request or Google Cloud Function connector.

steps:

- callCloudFunction:

call: http.post

args:

url: https://REGION-PROJECT_ID.cloudfunctions.net/FUNCTION_NAME

body:

key: value

Process Results:

Handle the response from the Cloud Function and proceed with the next steps in the Workflow, such as loading data into BigQuery.

Reference Links:

Google Cloud Functions Documentation

Using Workflows with Cloud Functions

Workflows Standard Library

A Reshuffle operation is a way to force Dataflow to split the pipeline into multiple stages, which can help isolate the performance of each step and identify bottlenecks. By monitoring the execution details in the Dataflow console, you can see the time, CPU, memory, and disk usage of each stage, as well as the number of elements and bytes processed. This can help you diagnose where the pipeline is slowing down and optimize it accordingly. References:

1: Reshuffling your data

2: Monitoring pipeline performance using the Dataflow monitoring interface

3: Optimizing pipeline performance

By specifying a worker region, you can run your Dataflow pipeline in a multi-zone or multi-region configuration, which provides higher availability and resilience in case of zonal failures1. The —region flag allows you to specify the regional endpoint for your pipeline, which determines the location of the Dataflow service and the default location of the Compute Engine resources1. If you do not specify a zone by using the —zone flag, Dataflow automatically selects a zone within the region for your job workers1. This option is recommended over submitting duplicate pipelines in two different zones, which would incur additional costs and complexity. Setting the pipeline staging location as a regional Cloud Storage bucket does not affect the availability of your pipeline, as the staging location only stores the pipeline code and dependencies2. Creating an Eventarc trigger to resubmit the job in case of zonal failure is not a reliable solution, as it depends on the availability of the Eventarc service and the zonal resources at the time of resubmission. References:

1: Pipeline troubleshooting and debugging | Cloud Dataflow | Google Cloud

3: Regional endpoints | Cloud Dataflow | Google Cloud

If you're running a performance test that depends upon Cloud Bigtable, be sure to follow these steps as you plan and execute your test:

Use a production instance. A development instance will not give you an accurate sense of how a production instance performs under load.

Use at least 300 GB of data. Cloud Bigtable performs best with 1 TB or more of data. However, 300 GB of data is enough to provide reasonable results in a performance test on a 3-node cluster. On larger clusters, use 100 GB of data per node.

Before you test, run a heavy pre-test for several minutes. This step gives Cloud Bigtable a chance to balance data across your nodes based on the access patterns it observes.

Run your test for at least 10 minutes. This step lets Cloud Bigtable further optimize your data, and it helps ensure that you will test reads from disk as well as cached reads from memory.

The Cloud Bigtable cluster doesn't have enough nodes. If your Cloud Bigtable cluster is overloaded, adding more nodes can improve performance. Use the monitoring tools to check whether the cluster is overloaded.

If you know the set of all possible feature values of a column and there are only a few of them, you can use categorical_column_with_vocabulary_list. Each key in the list will get assigned an auto-incremental ID starting from 0.

What if we don't know the set of possible values in advance? Not a problem. We can use categorical_column_with_hash_bucket instead. What will happen is that each possible value in the feature column occupation will be hashed to an integer ID as we encounter them in training.

When collecting and grouping data into windows, Beam uses triggers to determine when to emit the aggregated results of each window.

Processing time triggers. These triggers operate on the processing time – the time when the data element is processed at any given stage in the pipeline.

Event time triggers. These triggers operate on the event time, as indicated by the timestamp on each data element. Beam’s default trigger is event time-based.

You do not set a query language for each dataset. It is set each time you run a query and the default query language is Legacy SQL.

Standard SQL has been the preferred query language since BigQuery 2.0 was released.

In legacy SQL, to query a table with a project-qualified name, you use a colon, :, as a separator. In standard SQL, you use a period, ., instead.

Due to the differences in syntax between the two query languages (such as with project-qualified table names), if you write a query in Legacy SQL, it might generate an error if you try to run it with Standard SQL.

Apache Hive is a data warehouse software project built on top of Apache Hadoop for providing data summarization, query, and analysis.

Google BigQuery is an enterprise data warehouse.

When reading from a Dataflow source or writing to a Dataflow sink using DirectPipelineRunner, the Cloud Platform account that you configured with the gcloud executable will need access to the corresponding source/sink

To connect to the web interfaces, it is recommended to use an SSH tunnel to create a secure connection to the master node.

Cloud Bigtable is Google's NoSQL Big Data database service. It is the same database that Google uses for services, such as Search, Analytics, Maps, and Gmail.

It is used for requirements that are low latency and high throughput including Internet of Things (IoT), user analytics, and financial data analysis.

Categorical features in linear models are typically translated into a sparse vector in which each possible value has a corresponding index or id. For example, if there are only three possible eye colors you can represent 'eye_color' as a length 3 vector: 'brown' would become [1, 0, 0], 'blue' would become [0, 1, 0] and 'green' would become [0, 0, 1]. These vectors are called "sparse" because they may be very long, with many zeros, when the set of possible values is very large (such as all English words).

[0, 0, 0, 1, 0, 0, 1] is not a sparse vector because it has two 1s in it. A sparse vector contains only a single 1.

[0, 5, 0, 0, 0, 0] is not a sparse vector because it has a 5 in it. Sparse vectors only contain 0s and 1s.

Cloud Bigtable is not a relational database. It does not support SQL queries, joins, or multi-row transactions. It is not a good solution for less than 1 TB of data.

Google charges for storage, queries, and streaming inserts. Loading data from a file and exporting data are free operations.

When you apply a BigQueryIO.Write transform in batch mode to write to a single table, Dataflow invokes a BigQuery load job. When you apply a BigQueryIO.Write transform in streaming mode or in batch mode using a function to specify the destination table, Dataflow uses BigQuery's streaming inserts

One of the advantages of Cloud Dataproc is its low cost. Dataproc charges for what you really use with minute-by-minute billing and a low, ten-minute-minimum billing period.

Partitioned tables include a pseudo column named _PARTITIONTIME that contains a date-based timestamp for data loaded into the table. To limit a query to particular partitions (such as Jan 1st and 2nd of 2017), use a clause similar to this:

WHERE _PARTITIONTIME BETWEEN TIMESTAMP('2017-01-01') AND TIMESTAMP('2017-01-02')

Denormalization increases query speed for tables with billions of rows because BigQuery's performance degrades when doing JOINs on large tables, but with a denormalized data

structure, you don't have to use JOINs, since all of the data has been combined into one table. Denormalization also makes queries simpler because you do not have to use JOIN clauses.

Denormalization increases the amount of data processed and the amount of storage required because it creates redundant data.

Dataflow is a unified processing model, and can execute both streaming and batch data pipelines

The dataflow.worker role provides the permissions necessary for a Compute Engine service

account to execute work units for a Dataflow pipeline

The conventional method of denormalizing data involves simply writing a fact, along with all its dimensions, into a flat table structure. For example, if you are dealing with sales transactions, you would write each individual fact to a record, along with the accompanying dimensions such as order and customer information.

The other method for denormalizing data takes advantage of BigQuery’s native support for nested and repeated structures in JSON or Avro input data. Expressing records using nested and repeated structures can provide a more natural representation of the underlying data. In the case of the sales order, the outer part of a JSON structure would contain the order and customer information, and the inner part of the structure would contain the individual line items of the order, which would be represented as nested, repeated elements.

https://cloud.google.com/sql/docs/mysql/manage-connections#backoff

Reference https://support.google.com/datastudio/answer/7020039?hl=en

Reference https://medium.com/mlreview/a-simple-deep-learning-model-for-stock-price-prediction-using-tensorflow-30505541d877

To create a robust and resilient SQL pipeline in BigQuery that handles retries and failure notifications, consider the following:

BigQuery Scheduled Queries: This feature allows you to schedule recurring queries in BigQuery. It is a straightforward way to run SQL transformations on a regular basis without requiring extensive setup.

Error Handling and Retries: While BigQuery Scheduled Queries can run at specified intervals, they don't natively support complex retry logic or failure notifications directly. This is where additional Google Cloud services like Pub/Sub and Cloud Functions come into play.

Pub/Sub for Notifications: By configuring a BigQuery scheduled query to publish messages to a Pub/Sub topic upon failure, you can create a decoupled and scalable notification system.

Cloud Functions: Cloud Functions can subscribe to the Pub/Sub topic and implement logic to count consecutive failures. After detecting three consecutive failures, the Cloud Function can then send an email notification using a service like SendGrid or Gmail API.

Implementation Steps:

Set up a BigQuery Scheduled Query:

Create a scheduled query in BigQuery to run your SQL transformation every two hours.

Configure the scheduled query to publish a notification to a Pub/Sub topic in case of a failure.

Create a Pub/Sub Topic:

Create a Pub/Sub topic that will receive messages from the scheduled query.

Develop a Cloud Function:

Write a Cloud Function that subscribes to the Pub/Sub topic.

Implement logic in the Cloud Function to track failure messages. If three consecutive failure messages are detected, the function sends an email notification.

Reference Links:

BigQuery Scheduled Queries

Pub/Sub Documentation

Cloud Functions Documentation

SendGrid Email API

Gmail API

Option A is incorrect because VPC Network Peering alone does not enable connectivity to Cloud SQL instances with private IP addresses. You also need to configure private services access and allocate an IP address range for the service producer network1.

Option B is incorrect because Cloud NAT does not support Cloud SQL instances with private IP addresses. Cloud NAT only provides outbound connectivity for resources that do not have public IP addresses, such as VMs, GKE clusters, and serverless instances2.

Option C is correct because it allows you to use a Compute Engine instance as a proxy server to connect to the Cloud SQL database over the peered network. The proxy server does not need an external IP address because it can communicate with the Dataflow workers and the Cloud SQL instance using internal IP addresses. You need to install the Cloud SQL Auth proxy on the proxy server and configure it to use a service account that has the Cloud SQL Client role.

Option D is incorrect because it requires you to assign public IP addresses to the Dataflow workers, which exposes the data to the public internet. This violates the requirement of ensuring that the data does not go through the public internet. Moreover, adding authorized networks does not work for Cloud SQL instances with private IP addresses.
