To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in an MRN network with LO and LI restoration capabilities, you need to check the Logical Link box, set the Port Type to Unterminated, check the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LO or LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option enables the GMPLS control plane for the logical link, while the ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms - NATO

RSVP-TE Notify message is a message type defined in the RSVP-TE protocol, which is an extension of the RSVP protocol for MPLS traffic engineering. RSVP-TE Notify message is used to inform non-adjacent nodes of LSP events, such as setup, modification, or teardown. This allows the nodes to update their local state information and perform actions based on the notification. For example, a Notify message can be used to trigger a fast reroute mechanism in case of a link or node failure12. References:

• 1: RFC 3473 - Generalized Multi-Protocol Label Switching (GMPLS) Signaling Resource Reservation Protocol-Traffic Engineering (RSVP-TE) Extensions
• 2: RFC 3471 - Generalized Multi-Protocol Label Switching (GMPLS) Signaling Functional Description

The Shutting Down state is a transient state that occurs when a TE-link is set to maintenance mode in the NFM-T. In this state, the TE-link is not available for routing new LSPs, but the existing LSPs (SNCs) that use the TE-link are not immediately terminated. Instead, they are soft-rerouted, which means that they are gracefully switched to alternative paths without disrupting the traffic. The Shutting Down state lasts until all the SNCs on the TE-link are successfully soft-rerouted or forcefully terminated. After that, the TE-link transitions to the Administrative Maintenance state, where no traffic can be routed over the TE-link12. References:

• 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
• 2: Nokia Network Functions Manager for Transport User Guide | Nokia

 The Wait for Server Restoration (WSR) parameter in the MRN is a boolean parameter that determines whether an LI service should wait for the LO restoration or not in case of a failure.When WSR is false, the LI services do not wait for the LO restoration and restore through LI switching. This means that if an LO optical channel fails, the LI services that use that channel will switch to another available optical channel at LI layer without waiting for the LO layer to restore the failed channel. This option provides faster restoration time for LI services, but may result in suboptimal resource utilization at LO layer. When WSR is true, the LI services wait for the LO restoration and do not switch at LI layer. This means that if an LO optical channel fails, the LI services that use that channel will remain in that channel until the LO layer restores it or until a timeout occurs. This option provides optimal resource utilization at LO layer, but may result in longer restoration time for LI services. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3. GMPLS - Nokia

The SNC state with an uppercase “N” means that the resource is currently using the nominal resource assigned to it. As explained in the previous question, a nominal resource is the default or preferred resource that is assigned to an LSP when it is created. If an LSP is using the nominal resource on a TE-link, it means that the LSP has not been rerouted or switched due to any failure or constraint violation. In this case, the SNC state of the resource will be “N”, indicating that it is in use by an LSP12. References:

• 1: Nokia GMPLS-controlled Optical Networks Course | Nokia
• 2: Nokia Network Functions Manager for Transport User Guide | Nokia
