HPE2-W09 Questions and Answers

Aruba CX 8325 switches are an appropriate choice for leaf switches in a leaf-spine topology that uses Virtual Extensible LAN (VXLAN) with Ethernet VPN (EVPN) is a correct positioning of ArubaOS-CX switches in the data center. The Aruba CX 8325 switches are designed for data center spine or core roles, but they can also be used as leaf switches in a VXLAN with EVPN scenario. They support advanced features such as VSX, EVPN, and PFC that enable high performance, scalability, and resiliency for data center networks1.

NetEdit 2.0 is a network management tool that allows you to configure, monitor, and troubleshoot ArubaOS-CX switches. NetEdit 2.0 can discover switches using different methods, such as IP range scan, LLDP neighbors, or manual entry. After it discovers a switch, NetEdit 2.0 does not enable SNMP on the switch, if disabled. SNMP is a protocol that allows NetEdit 2.0 to collect information and statistics from the switches, but it is not required for discovery or management. NetEdit 2.0 can use other protocols, such as REST API or SSH, to communicate with the switches1. Therefore, this is not something that NetEdit 2.0 does after it discovers a switch.

A loopback interface can be attached to a VRF on an ArubaOS-CX switch. A loopback interface is a virtual interface that has an IP address assigned to it and is always up. A loopback interface can be attached to a VRF by using the vrf attach command under its configuration mode1.

Set the link-up delay timer based on the number of MAC forwarding, ARP, and routing table entries is a guideline for configuring the switches’ link-up delay settings for Virtual Switching Extension (VSX) fabric. The link-up delay timer defines how long a VSX node waits before advertising link state changes to its peer node. This allows the node to synchronize its MAC forwarding, ARP, and routing tables with its peer node before sending or receiving traffic on the newly activated link1.

VSX features a dual control plane while VSF features a single control plane. VSX and VSF are both high availability solutions that provide redundancy and load balancing across a pair of switches1. However, VSX features a dual control plane, which means that each switch has its own independent configuration and state information1. VSF features a single control plane, which means that one switch acts as the commander and synchronizes the configuration and state information to the other switch1. The statement is true because it correctly describes the difference between VSX and VSF control planes.

Place all three VRFs in the same OSPF process on Switch-1 is not a valid strategy for meeting this goal of enabling devices in VRF B and VRF C to reach shared resources in VRF A. This strategy would not work because OSPF does not support multiple VRFs in the same process on ArubaOS-CX switches. Each VRF must have its own OSPF process with a unique process ID1.

A schedule profile is a feature of ArubaOS-CX that determines the order and service of queues for transmission123. A schedule profile must be configured on every interface at all times23. The switch supports three scheduling algorithms: Guaranteed Minimum Bandwidth (GMB), Strict, and Strict EQS23. Strict scheduling gives absolute priority to a queue over other queues, regardless of the bandwidth allocation23. If the profile mixes strict priority scheduling with another scheduling algorithm, the strict priority queue must be the highest numbered queue23. Therefore, this is a rule for configuring schedule profiles on an ArubaOS-CX switch, and the correct answer is yes. For more information on schedule profiles and QoS, refer to the Aruba Data Center Network Specialist (ADCNS) certification datasheet1 and the QoS Guide for your switch model23.

You are not concerned about split brain issues in your environment, so you want the secondary member to keep its links up if the ISL fails is a use case for disabling split-recovery mode on ArubaOS-CX switches in a Virtual Switching Extension (VSX) fabric. VSX is a feature that provides active-active forwarding and redundancy for ArubaOS-CX switches. The ISL is the inter-switch link that connects two VSX nodes and carries data traffic. The split-recovery mode is a feature that prevents split-brain scenarios when both VSX nodes lose connectivity with each other but remain up. When split-recovery mode is disabled, if the ISL fails but both VSX nodes remain up,

With the exception of a single strict priority queue, all queues must use the same scheduling algorithm is a rule for configuring schedule profiles on an ArubaOS-CX switch. A schedule profile defines how traffic is scheduled across different queues on an interface. Each queue can have one of three scheduling algorithms: strict priority (SP), weighted round robin (WRR), or weighted fair queuing (WFQ). However, only one queue can have SP, and all other queues must have either WRR or WFQ1.

Configuring trust of CoS on the interface is a requirement for implementing Priority Flow Control (PFC) on an ArubaOS-CX switch interface. PFC is a feature that allows a switch to pause traffic on a per-class basis using IEEE 802.1Qbb frames. To use PFC, the switch must trust the CoS values in the incoming frames and map them to priority groups and queues1.

A broadcast arrives in VLAN 10 on Switch-1. Switch 1 forwards the frame on all interfaces assigned to VLAN 10, except the incoming interface. It encapsulates the broadcast with VXLAN and sends it to 192.168.1.3, but not 192.168.1.2 is not a correct explanation of how the switch handles the traffic. Switch-1, Switch-2, and Switch-3 are ArubaOS-CX switches that use VXLAN and EVPN to provide Layer 2 extension over Layer 3 networks. VXLAN is a feature that uses UDP encapsulation to tunnel Layer 2 frames over Layer 3 networks using VNIs. EVPN is a feature that uses BGP to advertise multicast information for VXLAN networks using IMET routes. Switch-1 receives a broadcast in VLAN 10, which belongs to VNI 5010. Switch-1 forwards the frame on all interfaces assigned to VLAN 10, except the incoming interface, as per normal Layer 2 switching behavior. However, Switch-1 does not encapsulate the broadcast with VXLAN and send it only to 192.168.1.3, which is Switch-2’s loopback interface, but rather replicates the broadcast, encapsulates each broadcast with VXLAN, and sends the VXLAN traffic to both 192.168.1.2 and 192.168.1.3, which are Switch-3’s and Switch-2’s loopback interfaces respectively.

Multi-tenancy is the ability to provide network services to multiple independent customers or tenants on a shared physical infrastructure. One of the challenges of multi-tenancy is to ensure isolation and security between different tenants, while also providing scalability and efficiency. Virtual Routing and Forwarding (VRF) is a data center technology that can help meet these requirements by enabling multiple isolated Layer 3 domains, each with its own routing table, to share a physical network1. VRF allows different tenants to use overlapping IP addresses and routing protocols without interfering with each other. Therefore, this is a valid way that a data center technology can help meet requirements for multi-tenancy.

ARP and ND Suppression are features of ArubaOS-CX that reduce the broadcast traffic on EVPN VXLAN networks1. ARP and ND Suppression enable the switch to reply to ARP and ND requests with information present in the local ARP and neighbor cache, instead of flooding them to all VTEPs1. This reduces the bandwidth consumption and improves the network performance1. When ARP-Suppression is enabled, the switch replies to ARP requests with information present in the local ARP Table2. Therefore, this statement about ARP and ND Suppression is true, and the correct answer is yes. For more information on ARP and ND Suppression, refer to the Aruba Data Center Network Specialist (ADCNS) certification datasheet3 and the EVPN VXLAN Guide for your switch model1.

You cannot leak multicast routes is a rule for the setup of multi-protocol BGP to implement dynamic VRF route leaking on an ArubaOS-CX switch. Multi-protocol BGP only supports unicast routes for route leaking, and multicast routes are not leaked between VRFs1.
